Description

9 / 100

SEO Score

Reference Ranges	Any range from -atm to 4000 bar, Type gauge or Absolute
Accuracy	0.01%FS or 0.025%FS or 0.05%FS or 0.1%FS (>1000bar)
Pressure Resolution	6 Full Digits
Temperature Compensation	0 to 50 Deg C to rated accuracy
Available Engineering Units	Mpa, bar, kg/cm2, kPa, psi, inH20, mmH20 and etc.
Reading update	20 ms @ 57600 baudrate
Response Time	< 0.2 Sec for a F.S pressure step
Over Pressure Ratings	150% FS
Cal Interval	365 days
Media	All media compatible to 316SS material

Power Supply	6-30 Vdc @ 25 mA
Communication	RS232 or RS485 or USB
Warm Up Time	5 minutes
Unit Size	51mm diameter x 155mm Lenght
Weight	300 grams
Storage Temperature/Humidity	-20 to 70 C / 10 to 90% RH
