Description

Pressure Specification
Internal Reference Ranges	-atm to 300 psig/psia or any range below
Accuracy	+/-0.025%FS, optional 0.01%FS
Display	5 or 6 digits depending on accuracy selected
Temperature Compensation	0 to 50 Deg C to rated accuracy
Selectable Engineering Units	PSI, Mpa, kPa, Pa, Bar, mBar, kg/cm2, inH20@20 Deg C, mmH20@20 Deg C
Control Stability	0.002%FS @ less than 15 secs
Media Compatibility	Built-in electric pump, self generate
Pressure Connection	1/4″, 3/8″, 1/2″ NPT Female
General Specification
mA Input Accuracy	0.025%FS (24 VDC Loop Power)
Display	4.3″ TFT Colour Touch Screen
Warm Up Time	10 minutes
Communication	RS232
Size	408 x 431 x 228 mm (>150psig) l 408 x 330 x 174 mm (<150psig)
Weight	12 kg
Power/Operating Hours	Re-chargable lead-acid battery, 8 hours per charge
